VSDISPLAY 7 Inch 1280X800 N070ICG-LD1 LCD Screen Capacitive Touch Panel with VGA LCD Controller Board
Product details
| Management number | 218485984 | Release Date | 2026/05/03 | List Price | $39.60 | Model Number | 218485984 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
LCD Controller Board: VGA LCD Board Work for LVDS Interface LCD ScreenInput Power Adapter:12Vdc More than 2A.Come In Standby Model When Not Input SignalStandby Model <1WVideo Input: VGAOSD: Brightness Contrast Auto Language And So OnLanguage:English French German Spanish Italian And So OnBoard Size:107mm x 52mm x 18mm7" N070ICG-LD1 1280X800 LCD Screen:Display Mode HS-IPS,Normally Black,TransmissiveResolution 1280(RGB)×800Outline Size:161 ×107×4.5 (H×V×D)Display Area:149.76 × 93.6 (H×V)Brightness:400 cd/m² (Typ.)Contrast Ratio:800:1 (Typ.) (TM) Viewing Angle:89/89/89/89 (Typ.)(CR≥10) [Left / Right / Up / Down]Signal Interface LVDS (1 ch, 6-bit),Connector,40 pinsBacklight LEDInput Voltage 3.3V (Typ.)Packing list:1× VGA LCD Controller Board RT2270C-A1× 7inch N070ICG-LD1 1280X800 LCD With Capacitive Touch Sensor VS070TC02-B11× LVDS Cable1× USB Controller Card1× USB Cable1× Keyboard With Cable(Please notice that there is no power supply in the package)
- Specifications:7 Inch N070ICG-LD1 1280X800 LCD screen LVDS interface with VGA LCD board
- Feature:7'' N070ICG-LD1 1280X800 LCD screen with capacitive touch sensor
- Advantages:To support VGA video input,it's easy to operate and use with capacitive touch screen;OSD supports multiple language,such like English French German Spanish Italian and so on,it' convenient to set and change
- Service:All the products are tested before package and shipment,if any problem of product,please feel free to contact us
- Packing list:1× VGA LCD Controller Board RT2270C-A;1× 7inch N070ICG-LD1 1280X800 LCD With Capacitive Touch Sensor VS070TC02-B1;1× LVDS Cable;1× USB Controller Card;1× USB Cable;1× Keyboard With Cable
| UPC | 619438586149 |
|---|---|
| Brand | VSDISPLAY |
| Resolution | 1280X800 |
| Screen Size | 7 Inches |
| Display Type | LCD |
| Manufacturer | VSDISPLAY |
| Screen Finish | Glossy |
| Native Resolution | 1280x800 |
| Display Technology | LCD |
| Additional Features | Touchscreen |
| Hardware Connectivity | Unknown |
