OMRON E5AC-RX2ASM-000 Digital Temperature Controller Relay Output NN

[Control outputs 1 and 2] Control output1: Relay output Control output2: None [No. of auxiliary outputs] 2 [Power supply voltage] 100 to 240 VAC, 50/60 Hz [Terminal type] Screw terminal blocks [Input type] Universal input [Operating voltage range] 85 to 110% of rated supply voltage [Power consumption] 7.0 VA max. at 100 to 240 VAC, and 4.2 VA max. at 24 VAC or 2.4 W max. at 24 VDC [Sensor input] Temperature input Thermocouple: K, J, T, E, L, U, N, R, S, B, W, or PL II Platinum resistance thermometer: Pt100 or JPt100 Infrared temperature sensor (ES1B): 10 to 70deg.C, 60 to 120deg.C, 115 to 165deg.C, or 140 to 260deg.C Analog input Current input: 4 to 20 mA or 0 to 20 mA Voltage input: 1 to 5 V, 0 to 5 V, or 0 to 10 V [Input impedance] Current input: 150 Ohm max., Voltage input: 1 M Ohm min.(Use a 1:1 connection when connecting the ES2-HB/THB.) [Control method] ON/OFF or 2-PID control (with auto-tuning) [Control output] Output specifications: SPST-NO, 250 VAC, 5 A (resistive load), electrical life: 100,000 operations,minimum applicable load: 5 V, 10 mA (reference value) [Auxiliary output] SPST-NO. relay outputs, 250 VAC [Potentiometer input] 100 Ohm to 10 k Ohm [Setting method] Digital setting using front panel keys [Indication method] 11-segment digital display and individual indicators Character height: PV: 25.0 mm, SV: 15.0 mm, MV: 9.5 mm Three displays Contents: PV/SV/MV, PV/SV/Multi-SP, or PV/SV/Remaining soak time, etc Numbers of digits: 4 digits each for PM, SV, and MV displays1

• Products that we ship is a Japan version. There may be only a Japanese manual, if manufacture produced only for using in Japan.<br> Even if you are injured using this, we shall not be responsible for any loss, damages and troubles.<br> Since the shipment from Japan, it will take time to delivery. We have the case that we cannot ship depending on a delivery place.
• It is not in stock or the case of shipping in the next business day after, we will contact you by e-mail.<br> 9:00 to 18:00(JST): Business hours (Saturday and Sunday, Spring holidays , Summer holidays, the New Year will be closed)
