Brixwell Adjustable Glass to Curb Mount Shower Door Pivot Hinge, Bottom Mount, Solid Forged Brass, Satin Finish, 3/8" and 1/2" Glass Thickness, 4" Overall Width, Frameless Shower Hardware

The Brixwell Adjustable Glass to Curb Mount Shower Door Pivot Hinge in Satin finish is designed for bottom mount installation in frameless shower enclosures, offering flexibility for top or bottom mounting with a clean appearance. Made from solid forged brass with precision machined stainless steel internal components, this hinge provides strength and reliability in glass hardware, shower hardware, and door hardware applications. It features dual precision wound stainless steel return springs that support self-centering 0 degree return and self-closing from a 25 degree door angle. An adjustable mechanism allows the closing position to be fine-tuned after installation up to 90 degree in or out. Using the included 3mm hex wrench, installers can loosen the adjustment screws, reposition the door, and re-tighten for accurate alignment. The non-mouse ear design improves adjustment and frameless styling, while the square-edged profile adds a modern appearance. Designed for use with 3/8" (10mm) and 1/2" (12mm) tempered glass, the hinge requires fabrication cutouts for proper fitting. Rated at 40 lbs per hinge, two hinges support shower doors up to 120 lbs with a maximum width of 36". Glass weight reference is 5.05 lbs/sf for 3/8" glass and 6.40 lbs/sf for 1/2" glass. Dimensional specifications include overall width of 4", overall height of 2-11/16", plate height to step (front) of 2-1/4", base thickness of 3/8", plate thickness of 3/16" per side, lip thickness of 1/16", end to end hole spacing (back plate) of 3-1/8", and vertical width of 7/8". Hardware includes stainless steel hex clamping screws, crosshead screws, and a hex wrench, all in matching satin finish.

• SOLID FORGED BRASS: Made from solid forged brass with satin finish, offering strength and consistent appearance that coordinates with shower hardware, door hardware, and glass hardware in frameless projects.
• DOOR CAPACITY RATINGS: Each hinge supports 40 lbs; two hinges carry up to 120 lbs with maximum width of 36", designed for frameless shower doors using 3/8" or 1/2" tempered glass panels requiring fabrication cutouts.
• DETAILED DIMENSIONS: Overall width 4", height 2-11/16", plate height to step 2-1/4", plate thickness 3/16", base thickness 3/8", lip thickness 1/16", back plate spacing 3-1/8" horizontal and 7/8" vertical width.
• SELF-CENTERING ACTION: Dual precision wound stainless steel springs provide smooth self-centering 0 degree return, with self-closing from 25 degree door angle, ensuring reliable operation in pivot hinge and frameless hinge designs.
• ADJUSTABLE FUNCTION: Closing position can be set up to 90 degree in or out after installation, using included 3mm hex wrench to loosen, align, and retighten screws for accurate fitting in glass mount and shower hardware setups.
• INSTALLATION HARDWARE: Includes stainless steel hex clamping screws, crosshead screws, and hex wrench in matching satin finish, supporting installation in shower hinge, mount hinge, and pivot hinge applications.
• Supplied with stainless steel clamping screws, crosshead screws, and hex wrench as mounting hardware.
